Product Data - Planer
Model number 3296
Identification number 0 603 296 0 . .
Planing depth 0 - 3/32" (0 - 2.5mm)
Rabbeting depth 0 - 15/16" (0 - 24mm)
Cutting width 3-1/4"(82mm)
( NOTE: This tool is designed for use with alternating current (AC) only.)
Accessory Listing
Rabbeting depth guide*
Deluxe angle/width fence*
Blade wrench 8mm*
Carbide reversible blade set*
HSS reversible blade conv. kit**
HSS reversible blade set**
Rustic reversible blade conv. kit**
Rustic reversible blade set**
( * = standard equipment)
(** = CAUTION: see section "Special Cutting Applications", before installing or using
these optional blade conv. kits or optional blade sets. )
Planer Components
1. Wing knob 12. Round knobs 23. Cutter drum
2. Rabbeting depth stop 13. Guide bracket 24. Planer blades
3. Depth adjustment knob 14. Wing knob 25. Rabbet guard
4. Chip exhaust ports 15. Wing knob 26. Blade holders
5. Depth scale 16. Width scale 27. Blade leveling screws
6. Port selector lever 17. Deluxe angle/width fence 28. Driven pulley
7. Trigger switch 18. Screw 29. Drive belt
8. "Lock-OFF" button 19. Drive belt cover 30. Drive pulley
9. Blade wrench 8mm 20. Chamfer V-groove 31. Tool rest
10. Front shoe 21. Clamping screws
11. Pivot fence 22. Rear shoe
(NOTE: planer components not illustrated on page 2 are illustrated elsewhere in this manual.)
