In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
Use the battery only in conjunction with your Bosch
power tool. This measure alone protects the battery
against dangerous overload.
The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally. An
internal short circuit can occur and the battery can burn,
smoke, explode or overheat.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic, and
for impact drilling in brick, concrete and stone.
The power tool can be used with an angle screw adapter, an
eccentric adapter or a drill chuck adapter.
The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Mounting
2 Torque presetting ring
3 Operating mode preselection ring
4 Gear selector
5 Battery unlocking button
6 Battery pack
7 Worklight
8 Battery charge-control indicator
9 Rotational direction switch
10 On/Off switch
11 Drill chuck adapter
12 Eccentric adapter
13 Angle screw adapter
14 Handle (insulated gripping surface)
15 Universal bit holder*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Cordless Drill/Driver AdvancedImpact 18
QuickSnap
Drill chuck
adapter
Eccentric
adapter
Angle screw
adapter
Article number
3 603 JA3 4.. –––
Rated voltage
V= 18 –––
No-load speed
– 1st gear
– 2nd gear
min
-1
min
-1
0–400
0–1350
–
–
–
–
–
–
Impact frequency at no-load
min
-1
0 –20250 –––
Max. torque for soft screwdriving appli-
cation according to ISO 5393 Nm 19
*
–––
Maximum torque, hard screwdriving ap-
plication according to ISO 5393
Nm 38
*
–––
Maximum drilling diameter (1st/2nd
gear)
– Steel
– Wood
– Brickwork
mm
mm
mm
10
30
10
–
–
–
–
–
–
–
–
–
Max. screw dia.
mm 8 –––
Chuck clamping range
mm 0.8 – 10 –––
Tool holder
6.42 (¼") –6.42 (¼")6.42 (¼")
Weight according to EPTA-Procedure
01:2014 kg 1.4* 0.3 0.3 0.3
* with adapter
** limited performance at temperatures <0 °C
