English | 19
Bosch Power Tools 1 609 92A 3B0 | (8.3.17)
6 Thumbwheel for orbit frequency preselection
7 Venting slots
8 Vibration-dampening auxiliary handle
(insulated gripping surface)*
9 Thread for auxiliary handle
10 Tool holder
11 180° light band
12 Plunge saw blade*
13 Sanding plate*
14 Sanding sheet*
15 Depth stop*
16 Segment saw blade*
17 Handle (insulated gripping surface)
18 Vacuum hose*
19 Vacuum connection*
20 Dust extraction*
21 Clamping lever of the dust extraction
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Sound emission values determined according to
EN 60745-2-4.
Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); Sound power level 93 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Working without auxiliary handle
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745-2-4:
Sanding: a
h
=6m/s
2
, K=1.5 m/s
2
,
Sawing with plunge cut saw blade: a
h
=16m/s
2
, K=1.5 m/s
2
,
Sawing with segment saw blade: a
h
=14m/s
2
, K=1.5 m/s
2
.
Working with auxiliary handle
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745-2-4:
Sanding: a
h
=6m/s
2
, K=1.5 m/s
2
,
Sawing with plunge cut saw blade: a
h
=20m/s
2
, K=2.5 m/s
2
,
Sawing with segment saw blade: a
h
=16m/s
2
, K=1.5 m/s
2
.
The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main
applications of the tool. However if the tool is used for differ-
ent applications, with different accessories or insertion tools
or is poorly maintained, the vibration emission may differ.
This may significantly increase the exposure level over the
total working period.
An estimation of the level of exposure to vibration should al-
so take into account the times when the tool is switched off
or when it is running but not actually doing the job. This may
significantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and
the accessories, keep the hands warm, organisation of work
patterns.
Assembly
Battery Charging
Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium-ion battery of your power tool.
Note: The battery supplied is partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
Note: If the machine should automatically switch off because
of a discharged or overheated battery, make sure to set the
machine’s On/Off switch 2 to off. Charge the battery and al-
low it to cool down before restarting the machine. Otherwise
the battery can become damaged.
Cordless Multifunction Tool AdvancedMulti 18
Article number 3 603 A04 0..
Preselection of
orbital stroke rate
Constant electronic control
Soft starting
AutoClic tool holder
Rated voltage
V= 18
No-load speed n
0
min
–1
10000–20000
Oscillation angle, left/right
°2.8
Weight according to
EPTA-Procedure 01:2014
– without auxiliary handle
– with auxiliary handle
kg
kg
1.5
1.6
Permitted ambient
temperature
–during charging
– during operation* and
during storage
°C
°C
0...+45
–20...+50
Recommended batteries
PBA 18V....V-.
PBA 18V....W-.
Recommended chargers
AL 18.. CV
* limited performance at temperatures <0 °C
Technical data determined with battery from delivery scope.
OBJ_BUCH-2966-001.book Page 19 Wednesday, March 8, 2017 9:58 AM
