Mounting and Operation
Working Advice
When operating, always hold the machine close to the
ground.
Do not blow hot, flammable or explosive material.
The garden vacuum is only suitable for foliage and garden
waste.
Please inspect the area for little animals and hard objects be-
fore using the tool.
Do not vacuum liquids, plastic bags, cans, pine cones,
branches larger than 5 mm (Ø >5 mm), cloth, tissues and
pegs.
Troubleshooting
Action Figure Page
Delivery Scope
1 10
Safety Cover Assembly
2 10
Tube Assembly
3 11
Connecting the extension lead
4 11
Starting
4 11
Stopping
4 11
Blow Mode
5 12
Selecting Blowing Speed
5 12
Tube/Safety Cover Disassembly
6 13
Handle Assembly
7 13
Vacuum Tube Assembly (one-
time assembly only)
8 14
Fitting of Shoulder Strap
9 14
Fitting of Collection Bag
10 15
Connecting the extension lead
11 15
Starting
11 15
Stopping 11 15
Vacuum Mode
12 16
Selecting Volume Flow Rate
12 16
Adjusting Front Handle
13 17
Emptying Collection Bag
14 17 – 18
Maintenance and Cleaning
15 18 – 19
Storage and Transport
16 19
Action Figure Page
Problem Possible Cause Corrective Action
Machine fails to operate Components not assembled correctly see “assembly”
Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Motor protector has activated Allow motor to cool down and check that fan is
not blocked
Machine functions
intermittently
Extension cable damaged Inspect cable, replace if damaged
Internal wiring of machine damaged Contact Service Agent
On/Off switch defective Contact Service Agent
Motor protector has activated Allow motor to cool down and check that fan is
not blocked
Excessive vibrations/
noise
Machine defective Contact Service Agent
Machine does not blow/
vacuum
Tube obstructed Clear tube
