English | 15
Bosch Power Tools F 016 L81 594 | (10.5.17)
Intended Use
This product is intended for blowing and collecting leaves and
garden waste such as grass clippings in the area around the
garden and house.
This product is not intended for use as a shredder.
It can be dangerous to operate any power tool in a manner
other than as specifically intended. Misuse can result in per-
sonal injury.
Technical Data
Noise/Vibration Information
Sound emission values determined according to
EN 50636-2-100.
Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); sound power level
102dB(A). Uncertainty K=3dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 50636-2-100:
a
h
<2.5m/s
2
, K =1.5 m/s
2
.
Mounting and Operation
Working Advice
When operating, always hold the machine close to the
ground.
Do not blow hot, flammable or explosive material.
The garden vacuum is only suitable for foliage and garden
waste.
Please inspect the area for little animals and hard objects be-
fore using the tool.
Do not vacuum liquids, plastic bags, cans, pine cones,
branches larger than 5 mm (Ø >5 mm), cloth, tissues and
pegs.
Motor is running only if the following parts are assembled:
– vacuum tube and collection bag in vacuum mode
– tube and intake grid in blow mode
Leaf blower/Garden Vacuum Cleaner ALS 2400 ALS 25 ALS 25 ALS 2500 ALS 28 ALS 30
Article number
3 600 ... HA1 001 HA1 0.. HA1 030
HA1 040
HA1 071 HA1 1.. HA1 1..
Rated power input
W 2400 2500 2300 2500 2800 3000
Air speed
km/h 180/300 180/300 180/300 180/300 180/300 180/300
Volume flow rate, max.
m
3
/h 400/800 400/800 400/800 400/800 400/800 400/800
Reduction ratio
10:1 10:1 10:1 10:1 10:1 10:1
Collection bag volume
l4545 45 45 45 45
Weight (blow mode)
kg 3.2 3.2 3.2 3.2 3.2 3.2
Weight (vacuum mode)
kg 4.4 4.4 4.4 4.4 4.4 4.4
Protection class
/II /II /II /II /II /II
Serial number
see type plate on the garden product
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Action Figure Page
Delivery Scope
1 238
Safety Cover Assembly
2 238
Tube Assembly
3 239
Connecting the extension lead
4 239
Starting
4 239
Stopping
4 239
Blow Mode
5 240
Selecting Blowing Speed
5 240
Tube/Safety Cover Disassembly
6 241
Handle Assembly
7 241
Vacuum Tube Assembly (one-time
assembly only)
8 242
Fitting of Shoulder Strap
9 242
Fitting of Collection Bag
10 243
Connecting the extension lead 11 243
Starting
11 243
Stopping
11 243
Vacuum Mode
12 244
Selecting Volume Flow Rate
12 244
Adjusting Front Handle
13 245
Emptying Collection Bag
14 245 – 246
Maintenance and Cleaning
15 246 – 247
Storage and Transport
16 247
Action Figure Page
OBJ_BUCH-2968-003.book Page 15 Wednesday, May 10, 2017 2:58 PM
