Noise/Vibration Information
Sound emission values determined according to
EN 50636-2-100.
Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); sound power level
102dB(A). Uncertainty K=3dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 50636-2-100:
a
h
<2.5m/s
2
, K =1.5 m/s
2
.
Mounting and Operation
Working Advice
When operating, always hold the machine close to the
ground.
Do not blow hot, flammable or explosive material.
The garden vacuum is only suitable for foliage and garden
waste.
Please inspect the area for little animals and hard objects be-
fore using the tool.
Do not vacuum liquids, plastic bags, cans, pine cones, bran-
ches larger than 5 mm (Ø >5 mm), cloth, tissues and pegs.
Motor is running only if the following parts are assembled:
–vacuum tube and collection bag in vacuum mode
–tube and intake grid in blow mode
Troubleshooting
Action Figure Page
Delivery Scope
1 19
Safety Cover Assembly
2 19
Tube Assembly
3 20
Connecting the extension lead
4 20
Starting
4 20
Stopping
4 20
Blow Mode
5 21
Selecting Blowing Speed
5 21
Tube/Safety Cover Disassembly
6 22
Handle Assembly
7 22
Vacuum Tube Assembly (one-time
assembly only)
8 23
Fitting of Shoulder Strap
9 23
Fitting of Collection Bag 10 24
Connecting the extension lead
11 24
Starting
11 24
Stopping
11 24
Vacuum Mode
12 25
Selecting Volume Flow Rate
12 25
Adjusting Front Handle
13 26
Emptying Collection Bag
14 26–27
Maintenance and Cleaning
15 27–28
Storage and Transport
16 28
Action Figure Page
Problem Possible Cause Corrective Action
Machine fails to operate Components not assembled correctly see assembly
Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Motor protector has activated Allow motor to cool down and check that fan is
not blocked
