English | 15
Bosch Power Tools F 016 L81 048 | (17.2.15)
Mounting and Operation
Troubleshooting
After-sales Service and Application
Service
www.bosch-garden.com
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the garden product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com
Action Figure Page
Delivery Scope
1 202
Wheel Assembly
2 203
Handle Assembly
3 204
Snap together the Grassbox
Grassbox fitting/removing
4 205
Adjusting the Cutting Height
5 205
Starting 6 206
Stopping
6 206
Working Advice
7 207
Blade Maintenance
8 207
Selecting Accessories
9 208
Action Figure Page
Problem Possible Cause Corrective Action
Motor refuses to start Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Grass too long Increase height of cut and tilt garden product
to reduce starting load
Motor protector has activated Allow motor to cool and increase height of cut
Machine functions
intermittently
Extension cable damaged Inspect cable, replace if damaged
Internal wiring of machine damaged Contact Service Agent
Motor protector has activated Allow motor to cool and increase height of cut
Machine leaves ragged finish
and/or
Motor labours
Height of cut too low Increase height of cut
Cutting blade blunt Replace the blade
Possible clogging Check underneath the garden product and
clear out as necessary (always wear protective
gloves)
Blade fitted upside down Refit blade correctly
Blade not rotating while garden
product switched on
Cutting blade obstructed Switch off garden product
Clear obstruction (always wear protective
gloves)
Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Excessive vibrations/noise Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Cutting blade damaged Replace the blade
