EURO • Printed in England • BA F 016 L69 883 • ASM 32/32 F • GB • OSW 02/01
English - 2
Cylinder Mower ASM 32 ASM 32 F
Part number 0 600 889 0.. 0 600 889 1..
Rated power 360 W 340 W
Blade width 32 cm 32 cm
Height of cut 12 – 32 mm 12 – 42 mm
Grassbox capacity 31 l 23 l
Weight 13.5 kg 13.5 kg
Protection class / II / II
Serial Number See serial No 10 (rating plate)
on machine
This product is intended for domestic lawn mowing.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is important
that you read these instructions carefully.
When fully assembled the machine weighs approxi-
mately 13,5 kg. If necessary, obtain assistance to
remove from packaging.
Take care when carrying the mower to the lawn, as
the blades are sharp.
Carefully remove the machine from its packaging
and check that you have all the following items:
– Lawnmower with handle assembly
– 2 Bolts (fitted to handle)
– 2 Wing nuts (fitted to handle)
– 2 Grassbox halves ASM 32
– Grassbox ASM 32 F
– Operating instructions
When parts are missing or damaged, please contact your
dealer.
1 Handlebar
2 Switch lever
3 Safety button
4 Mains plug**
5 Cable restraint
6 Handle bottom
7 Grassbox
8 Height of cut lever
9 Ventilation slots
10 Serial Number
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Electrical Safety
Your machine is double insulated for safety and re-
quires no earth connection. The operating voltage is
230 V AC, 50 Hz. Only use approved extension ca-
bles. Contact your service agent for details.
Extension cords/leads should only be used if they
comply with H05VV-F or H05RN-F types.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
For products not sold in GB: WARNING: For
safety, it is essential that the mains plug 4 attached
to the machine is fitted to the power supply cable 11.
The couplings of connection leads must be pro-
tected against splashes and the coupling sockets on
the leads must be made of rubber or coated with
rubber.
Fixing means for the connection leads must be
used.
The connection lead must be inspected for signs of
damage at regular intervals and may only be used if
in perfect condition.
If the supply cord is damaged, it must be replaced by
a Bosch Service Center.
Products sold in GB only: Your mower is fitted with
an approved 13 A (BS 1363/A) electric plug and is
protected by a 13 A fuse (ASTA Approved to
BS 1362).
If the fitted plug is not suitable for your socket out-
lets, it should be cut off and an appropriate plug fit-
ted in its place.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be inserted
into a 13 A socket elsewhere.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
For Your Safety
Warning! Switch off, remove plug from mains
before adjusting, cleaning or if cable is cut,
damaged or entangled.
The blades continue to rotate for a few sec-
onds after the machine is switched off.
Caution - do not touch rotating blades.
B
F016 L69 883.book Seite 2 Dienstag, 15. Januar 2002 8:38 08
12 • F016 L69 883 • 02.01
