Adjusting a refrigerator
door
If the height of the refrigerator doors
is uneven:
1. Determine which refrigerator door
needs to be raised.
2. Tur n the screw nut on the lower
hinge to adjust the refrigerator door.
To raise a refrigerator door:
Tur n the screw counterclockwise.
To lower a refrigerator door:
Tur n the screw clockwise.
If the refrigerator doors are not
properly aligned:
WARNING
Risk of electric shock!
Before removing the top panel:
1. Shut off the water supply to the
appliance.
2. Unplug the appliance or switch
off the fuse.
1. Determine which refrigerator door
needs adjustment.
2. Remove the five screws on the top
panel.
3. Raise the panel.
4. Loosen the screw.
Do not remove the screw!
Figure
5. Move the hinge sideways to adjust
the refrigerator door.
6. Tighten the screw.
7. Realign panel.
8. Insert and tighten the five screws.
Adjusting the freezer
compartment drawer
1. Determine which side needs
adjustment.
2. Loosen the two screws.
Do not remove the screws!
3. Use the top screw to adjust the
freezer compartment drawer.
4. Tighten the two screws.
en
