English – 9
(6)
(5)
(3)
(7)
(1)
(13)
(10)
(9)
(11)
(12)
(1)
(10)
(2)
All representations of bike components are schematic
and can deviate from your eBike.
(1)
Key for the battery lock
(2)
Battery lock
(3)
PowerTube battery safety hook
(5)
Socket for charging connector
(6)
Operation/battery charge indicator
(7)
On/off button
(9)
Locking mechanism
(10)
Pull strap
(11)
Axial rail
(12)
PowerTube battery (axial)
(13)
Upper axial PowerTube holder
