Bosch BBS240 Original Instructions

Page 9
English–2
0 275 007 XPX | (4.5.17) Bosch eBike Systems
Product Description and
Specifications
Product Features
The numbering of the product features refers to the illustra-
tions on the graphics pages.
All representations of bike components, with exception of the
battery packs and their holders, are schematic and can
deviate from your eBike.
In addition to the functions shown here, changes to software
relating to troubleshooting and functional enhancements may
be introduced at any time.
1 Holder of the rack-type battery pack
2 Rack-type battery pack
3 Operation and charge-control indicator
4 On/Off button
5 Key of the battery pack lock
6 Battery-pack lock
7 Upper holder of the standard battery pack
8 Standard battery pack
9 Bottom holder of the standard battery pack
10 Cover lid (Supplied only on eBikes with 2 battery packs)
11 Battery charger
12 Socket for charge connector
13 Charge socket cover
14 PowerTube safety restraint
15 PowerTube frame battery
16 PowerTube safety hook
Technical Data
Assembly
 Place down the battery pack only on clean surfaces. In
particular, avoid soiling the charge socket and the con-
tacts, e. g. by means of sand or soil.
Checking the Battery Pack Before Using for the
First Time
Check the battery pack before charging it or using it with your
eBike for the first time.
For this, press the On/Off button 4 to switch on the battery
pack. When no LED of the charge-control indicator 3 lights up,
the battery pack may be damaged.
When at least one, but not all LEDs of the charge-control
indicator 3 is lit, then fully charge the battery pack before
using for the first time.
 Do not attempt to charge or use a damaged battery
pack. Please refer to an authorised Bosch eBike dealer.
Lithium-ion battery pack PowerPack 300 PowerPack 400 PowerPack 500 PowerTube
Article number
0 275 007 547
S)
*
0 275 007 548
S)
*
0 275 007 549
S)
*
0 275 007 513
R)
*
0 275 007 510
S)
0 275 007 512
S)
0 275 007 514
R)
0 275 007 522
R)
0 275 007 525
R)
0 275 007 526
R)
0 275 007 529
S)
0 275 007 530
S)
0 275 007 531
R)
0 275 007 532
R)
0 275 007 539
0 275 007 540
Rated voltage
V= 36 36 36 36
Rated capacity
Ah 8.2 11 13.4 13.4
Energy
Wh 300 400 500 500
Operating temperature
°C –10...+40 –10...+40 –10...+40 –10...+40
Storage temperature
°C –10...+60 –10...+60 –10...+60 –10...+60
Allowable charging temperature
range
°C 0...+40 0...+40 0...+40 0...+40
Weight, approx.
kg 2.5/2.6 2.5/2.6 2.6/2.7 2.8
Degree of protection
IP 54 (dust and
splash water
protected)
IP 54 (dust and
splash water
protected)
IP 54 (dust and
splash water
protected)
IP 54 (dust and
splash water
protected)
S) Standard battery pack
R) Rack-type battery pack
* Cannot be used in combination with other batteries in systems with two batteries
