-5-
CHARGER
CORD
CHANNEL REEL
RED LIGHT
GREEN LIGHT
FIG. 1
This charger will only charge the following batteries:
18 V: BAT600 - BAT650, WCBAT612 - WCBAT625
36 V: BAT810 - BAT840
For most up to date battery compatibility, please refer to
www.boschtools.com
Charger voltage rating:
120 V~ 60 Hz
SAVE THESE INSTRUCTIONS
18 V
BATTERY PACK
36 V BATTERY
PACK
TEMPERATURE
CONTROL
INDICATOR
(RED)
BATTERY
CHARGE
INDICATOR
(GREEN)
Indicators on 36 V Batteries
During the charging procedure, the three green
charge indicators of the battery light up one
after the other and briefly go out. The battery is
fully charged when the three green indicators
light up continuously. In approximately 5
minutes after the battery has been fully
charged, the three green indicators go out
again (Fig. 1).
When the red temperature control indicator
lights up when placing the battery into the
charger, the temperature of the battery is not
within the charge-temperature range (see
“Important Charging Notes”). The battery
cannot be charged until after the allowable
operating temperature range has been
reached.
Cord Reel Feature
The charger is equipped with a cord channel
reel, which will allow the user to wrap the power
cord around charger when not in use (Fig. 1).
