MASONRY/CONCRETE DRILLING
ITEM # DH507 11321EVS DH712VC 11316EVS DH1020VC 11335K
BH2760VC/
BH2760VCB/
BH2770VC
DRIVE SYSTEM
HAMMER
CLASSIFICATION
Demolition Demolition Demolition Demolition Demolition Breaker Breaker
AMPERAGE 10.0 13.0 14.5 14.0 15.0 15.0 15.0
IMPACT ENERGY*
(FT.-LBS.)
5.6 EPTA 6.1 EPTA 9.6 EPTA 12.4 EPTA 17.0 EP TA 22.0 EPTA
35.0 EPTA/
43.0 EPTA
NO LOAD BPM 1,350–2,800 1,300–2,900 1,380–2,760 900–1,890 850–1,800 1,300 1,000
VIBRATION
CONTROL
No
Hammer
Mechanism
and Handle
Hammer
Mechanism
and Handle
No
Hammer
Mechanism
and Handle
Hammer
Mechanism
and Handle
Hammer
Mechanism
and Handles
**VIBRATION
LEVELS M/S
2
14.0 11.0 9.5 18.5 8.0 13.0 8.5
MODES OF
OPERATION
Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only
LENGTH 17.5" 18.6" 21.3" 22.5" 27. 5" 30.4" 30.75"
WEIGHT 12.4 lbs. 13.7 lbs. 18.3 lbs. 22.5 lbs. 25.1 lbs. 38.0 lbs. 63.2 lbs.
ITEM # RH540M RH540S 11264EVS 11265EVS RH745 RH850VC RH1255VC
DRIVE SYSTEM
HAMMER
CLASSIFICATION
Combination Combination Combination Combination Combination Combination Combination
AMPERAGE 12.0 12.0 13.0 13.0 13.5 14.5 15.0
IMPACT ENERGY*
(FT.-LBS.)
6.1 EPTA 6.1 EPTA 6.5 EPTA 6.5 EPTA 8.2 EPTA 9.3 EPTA 14.1 EPTA
MAX. CONCRETE
CAPACITY
1-9/16" 1-9/16" 1-5/8" 1-5/8" 1-3/4" 1-7/8" 2"
OPTIMAL RANGE 1/2"–1-3/8" 1/2"–1-3/8" 1/2"–1-7/16" 1/2"–1-7/16" 5/8"–1-9/16" 3/4"–1-3/4" 1"–2"
THRU HOLE BITS 2-1/2" 2-1/2" 2-9/16" 2-9/16" 3-1/8" 3-1/8" 3-1/8"
CORE BITS 4" 4" 4-1/8" 4-1/8" 5" 6" 6"
NO LOAD RPM 170–340 170–340 170–340 170–340 150–305 150–305 100–220
NO LOAD BPM 1,500–2,900 1,500–2,900 1,700–2,900 1,700–2,900 1,380–2,760 1,380–2,750 1,000–2,150
VIBRATION
CONTROL
No No
Hammer
Mechanism
and Handle
Hammer
Mechanism
and Handle
No
Hammer
Mechanism,
Counter Balance
and Handle
Hammer
Mechanism
and Handle
**VIBRATION
LEVELS M/S
2
Drilling: 12.5 Drilling: 12.5 Drilling: 10.5 Drilling: 10.5 Drilling: 18.5 Drilling: 8.0 Drilling: 10.0
Chiseling: 10.0 Chiseling: 10.0 Chiseling: 7.5 Chiseling: 7.5 Chiseling: 14.0 Chiseling: 7.0 Chiseling: 8.0
MODES OF
OPERATION
Rotary Hammer
and Hammer
Only
Rotary Hammer
and Hammer
Only
Rotary Hammer
and Hammer
Only
Rotary Hammer
and Hammer
Only
Rotary Hammer
and Hammer
Only
Rotary Hammer
and Hammer
Only
Rotary Hammer
Hammer Only
LENGTH 19.0" 19.0" 19.25" 19.25" 21.0" 21.4" 23.6"
WEIGHT 15.2 lbs. 15.0 lbs. 15.2 lbs. 15.1 lbs. 18.5 lbs. 19.7 lbs. 26.2 lbs.
*Based on EPTA (European Power Tool Association) guidelines
**Per EPTA EN 60745
*Based on EPTA (European Power Tool Association) guidelines
**Per EPTA EN 60745
SPLINE SPLINE
HEX
COLLAR
HEX
COLLAR
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
SDS
max
