CONDENS A TE DRAIN TRA P
Unit
DO NO T OVE R TIGHTEN DRAIN FITTING
T O W ARD DRAIN CONNECTION
UNI T MUS T BE SLIGHT L Y INCLINED
"
2
"2
T O APPROVED DRAIN
The condensate trap is not mandatory
but is recommended for e f ficienc y .
Figure 8
secondary
primary
secondary
primary
Figure 9
