Bosch BMAC3036BNTD - Dimensional data

6
|
Bosch Multi-Position Cased Coils Installation Manual
03.2017 | Bosch Thermotechnology Corp.Data subject to change
2.4 Dimensional data
LIQUID LINE CONNECTION
V APOR LINE CONNECTION
APOR LINE CONNECTION
AUXILIA R Y DRAIN CONNECTION
3/4'' NP T FEMALE PIPE THREAD
T O P AIR S T O P
'
' 0 2
1 W
AUXILIA RY DRAIN CONNECTION
AUXILIA RY DRAIN
CONNECTION
3/4'' NP T FEMALE PIPE THREAD
3/4'' NP T FEMALE
PIPE THREAD
PRIMA RY DRAIN CONNETION
PRIMA RY DRAIN
CONNETION
3/4'' NP T FEMALE PIPE THREAD
3/4'' NP T FEMALE
PIPE THREAD
V APOR LINE CONNECTION
COPPER (SWE A T)
LIQUID LINE CONNECTION
COI L ACCESS
P ANE L
” 1
2
W
H
”
9 1
A
Figure 3
Model
Dimensions inch [mm]
Weight /Shipping
(LBS [kg])
Unit Height "H" Unit Width "W" Supply Duct "A" "W1" Liquid line /Vapor Line
BMAC2430ANTD 20 [508] 14½ [368] 13 [330] 13½ [343] ⅜ / ¾ 44.1 / 64.8 [20.0/29.4]
BMAC2430BNTD 20 [508] 17½ [445] 16 [407] 16½ [419] ⅜ / ¾ 46.7 /69.7[21.2/31.6]
BMAC2430CNTD 20 [508] 21 [553] 19½ [495] 20 [508] ⅜ / ¾ 50.5/77.6[22.9/35.2]
BMAC3036ANTD 20 [508] 14½ [368] 13 [330] 13½ [343] ⅜ / ¾ 44.1/64.8[20.0/29.4]
BMAC3036BNTD 20 [508] 17½ [445] 16 [407] 16½ [419] ⅜ / ¾ 46.7/69.7[21.2/31.6]
BMAC3036CNTD 20 [508] 21 [553] 19½ [495] 20 [508] ⅜ / ¾ 50.5/77.6[22.9/35.2]
Table 1
