Installation Manual Bosch Multi-Position Cased Coils | 13
Bosch Thermotechnology Corp. | 03.2017
Data subject to change
Water blow-off could occur in certain installation positions if the airfl ow
setting exceeds the maximum values listed.
Model / Coil
Maximum airfl ow setting,CFM
Upfl ow Horizontal Left Downfl ow Horizontal Right
BMAC2430ANTD
1125 1050 1050 1125
BMAC2430BNTD
1125 1050 1050 1125
BMAC2430CNTD
1250 1200 1050 1250
BMAC3036ANTD
1200 1050 1050 1200
BMAC3036BNTD
1250 1200 1050 1250
BMAC3036CNTD
1250 1200 1050 1250
BMAC4248BNTF
1800 1800 1700 1500
BMAC4248CNTF
1800 1800 1700 1700
BMAC4248DNTF
1800 1800 1700 1800
BMAC4860CNTF
1850 1850 1750 1750
BMAC4860DNTF
2000 2000 1850 1850
Table 3
