Bosch BMAC4248BNTF - Page 8

8
|
Bosch Multi-Position Cased Coils Installation Manual
03.2017 | Bosch Thermotechnology Corp.Data subject to change
LIQUID LINE CONNECTION
V APOR LINE CONNECTION
AUXILIA R Y DRAIN CONNECTION
3/4'' NP T FEMALE PIPE THREAD
T O P AIR S T O P
' ' 0 2
1 W
AUXILIA RY DRAIN CONNECTION
AUXILIA RY DRAIN
CONNECTION
3/4'' NP T FEMALE PIPE THREAD
3/4'' NP T FEMALE
PIPE THREAD
PRIMA RY DRAIN CONNETION
PRIMA RY DRAIN
CONNETION
3/4'' NP T FEMALE PIPE THREAD
3/4'' NP T FEMALE
PIPE THREAD
V APOR LINE CONNECTION
COPPER (SWE A T)
LIQUID LINE CONNECTION
COI L ACCESS
P ANE L
”
1
2
W
H
” 9
1
A
Figure 5
Model
Dimensions inch [mm]
Weight /Shipping
(LBS [kg])
Unit Height "H" Unit Width "W" Supply Duct "A" "W1" Liquid line /Vapor Line
BMAC4860CNTF 30 [762] 21 [533] 19½ [495] 20 [508] ⅜ /⅞ 82.2/109.6[37.3/49.7]
BMAC4860DNTF 30 [762] 24½ [622] 23 [584] 23½ [597] ⅜ /⅞ 86.4/117.0[39.2/53.1]
Table 3
