Bosch DAF220 - Transferring of Angles; Protractor

| 11
Bosch Power Tools 2 609 140 572 | (8.9.08)
– The leg extension can be extend-
ed out up to 6-3/4" or 170 mm
(see Figure A).
– When the extension is used in
this way, the “tool-interior an-
gle” w is displayed though it is
the “tool-exterior angle” v that
is needed (see Figure G). To
determine the “tool-exterior
angle”, subtract displayed angle
measurement from 180°
(v = 180°–w).
Examples of Leg Extension Usage
– Figure G illustrates the measure-
ment of a stairway step’s angle.
– Figure H illustrates the measure-
ment of the angle of the top of a
ventilation shaft that is to be
covered.
– Figure I illustrates the measure-
ment of a sloped window’s angle.
Transferring of Angles
(See Figure D)
The Miterfinder™ can also be used
to copy existing angles from one lo-
cation to another:
1 Measure the angle to be copied
and keep the tool opened to that
angle.
2 Place the contact edges of the
tool onto the structure or work-
piece and use the tool as a
straight edge to mark both legs
of the intended angle location.
Protractor
The Miterfinder™ can also be used
to position a workpiece or intended
cut line at exactly the desired angle
1 Open the tool to the desired
angle.
2 Please the tool into the intended
position of the work.
3 Use the tool as a straight edge to
mark both legs of the intended
angle location.
