| 7
Bosch Power Tools 2 609 140 572 | (8.9.08)
– Compound Miter Cut Calcula-
tor – Determines the exact miter
and bevel settings needed for
compound miter cuts, such as
crown molding cut
– Level – Built-in vertical and
horizontal spirit levels.
Product Features
1 Display Window
2 Adjustable Leg
3 Contact Edges
4 Battery Compartment Cover
5 RECALL/HOLD Button
6 Main Leg
7 End Cap
8 Spirit Level for vertical
alignment
9 Spirit Level for horizontal
alignment
10 LCD Display
11 ON/CLEAR/OFF & SIMPLE MTR
button
12 COMPOUND MTR button
13 Joint Cover
14 Leg Extension
15 Carrying Case
Display Element
a Angle Display
b Battery Power Indicator
c Spring Angle Indicator
(Input Angle No. 1 Indicator)
d Corner Angle Indicator
(Input Angle No. 2 Indicator)
e Miter Angle Indicator
f Bevel Angle Indicator
g HOLD (Memory) Indicator
