Error Code Indication
The components of the eBike system are continuously
and automatically monitored. If an error is detected, the
corresponding error code will appear in the speed indica-
tion a.
Depending on the type of error, the drive unit is automatically
shut off, if required. Continued travel without assistance from
the drive unit is possible at any time. However, have the eBike
checked before attempting new trips.
 Have all repairs performed only by an authorised bike
dealer.
Code Cause Corrective Measure
410
One or more buttons of the on-board
computer are blocked.
Check if any buttons are blocked, e.g. from dirt or debris. Clean the but-
tons, if required.
414
Connection problem of the operating
unit
Have connections and contacts checked.
418
One or more buttons of the operating
unit are blocked.
Check if any buttons are blocked, e.g. from dirt or debris. Clean the but-
tons, if required.
419
Configuration error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
422 Connection problem of the drive unit Have connections and contacts checked.
423
Connection problem of the eBike bat-
tery pack
Have connections and contacts checked.
424
Communication error among the com-
ponents
Have connections and contacts checked.
426
Internal time-out error Restart the system. If the problem persists, contact your Bosch eBike
dealer. In this error status, it is not possible to display or adjust the wheel
circumference in the basic settings menu.
430
Internal battery pack of the on-board
computer is empty.
Charge the on-board computer (in the holder or via the USB port).
431
Software version error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
440
Internal error of the drive unit Restart the system. If the problem persists, contact your Bosch eBike
dealer.
450 Internal software error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
460
Error at USB connection Remove the cable from the USB connection of the on-board computer.
If the problem persists, contact your Bosch eBike dealer.
490
Internal error of the on-board com-
puter
Have the on-board computer checked.
500 Internal error of the drive unit Restart the system. If the problem persists, contact your Bosch eBike
dealer.
502 Bike lighting error Check the light and the associated wiring. Restart the system. If the prob-
lem persists, contact your Bosch eBike dealer.
503
Error of the speed sensor Restart the system. If the problem persists, contact your Bosch eBike
dealer.
510 Internal sensor error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
511
Internal error of the drive unit Restart the system. If the problem persists, contact your Bosch eBike
dealer.
530
Battery pack error Switch off the eBike, remove the eBike battery pack and reinsert the
eBike battery pack. Restart the system. If the problem persists, contact
your Bosch eBike dealer.
OBJ_BUCH-2819-001.book Page 4 Wednesday, April 13, 2016 3:29 PM

Bosch Drive Unit Series Specifications

General

Motor Type	Mid-drive
Max Torque	85 Nm
Support Level	Eco, Tour, Sport, Turbo
Voltage	36 V
Model	Performance Line CX
Maximum Torque	85 Nm
Maximum Power	250 W
Water Resistance	IP54
Product line compatibility	Active Line, Active Line Plus, Performance Line
Battery Compatibility	Bosch PowerTube and PowerPack
Assistance Levels	Eco, Tour, Sport, Turbo
Display Compatibility	Intuvia, Nyon, Purion
Gear Sensor	Optional
