Bosch Drive Unit Series User Manual

English–5
1 270 020 XBP | (13.4.16) Bosch eBike Systems
531 Configuration error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
540
Temperature error The eBike is outside of the permissible temperature range. Switch off the
eBike system and allow the drive unit to either cool down or heat up to the
permissible temperature. Restart the system. If the problem persists,
contact your Bosch eBike dealer.
550
An improper load was detected. Remove load. Restart the system. If the problem persists, contact your
Bosch eBike dealer.
580
Software version error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
591 Authentication error Switch off the eBike system. Remove the battery pack and reinsert it.
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
592
Incompatible component Insert a compatible display. If the problem persists, contact your Bosch
eBike dealer.
593
Configuration error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
595, 596
Communication error Check the wiring to the transmission and restart the system. If the
problem persists, contact your Bosch eBike dealer.
602 Internal battery pack error while
charging
Unplug the charger from the battery pack. Restart the eBike system. Plug
the charger into the battery pack. If the problem persists, contact your
Bosch eBike dealer.
602
Internal battery pack error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
603
Internal battery pack error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
605 Battery pack temperature error The eBike is outside of the permissible temperature range. Switch off the
eBike system and allow the drive unit to either cool down or heat up to the
permissible temperature. Restart the system. If the problem persists,
contact your Bosch eBike dealer.
605
Battery pack temperature error while
charging
Unplug the charger from the battery pack. Allow the battery pack to cool.
If the problem persists, contact your Bosch eBike dealer.
606 External battery pack error Check the wiring. Restart the system. If the problem persists, contact
your Bosch eBike dealer.
610
Battery pack voltage error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
620
Charging error Replace the charger. Contact your Bosch eBike dealer.
640
Internal battery pack error Restart the system. If the problem persists, contact your Bosch eBike
dealer.
655 Multiple battery pack errors Switch off the eBike system. Remove the battery pack and reinsert it.
Restart the system. If the problem persists, contact your Bosch eBike
dealer.
656
Software version error Contact your Bosch eBike dealer so that he can perform a software
update.
7xx
Transmission error Please observe the operating instructions provided by the transmission
manufacturer.
No display Internal error of the on-board
computer
Restart your eBike system by switching it off and back on.
Code Cause Corrective Measure
OBJ_BUCH-2819-001.book Page 5 Wednesday, April 13, 2016 3:29 PM

Bosch Drive Unit Series Specifications

General

Motor Type	Mid-drive
Max Torque	85 Nm
Support Level	Eco, Tour, Sport, Turbo
Voltage	36 V
Model	Performance Line CX
Maximum Torque	85 Nm
Maximum Power	250 W
Water Resistance	IP54
Product line compatibility	Active Line, Active Line Plus, Performance Line
Battery Compatibility	Bosch PowerTube and PowerPack
Assistance Levels	Eco, Tour, Sport, Turbo
Display Compatibility	Intuvia, Nyon, Purion
Gear Sensor	Optional
