Table of contents
21
Easy
Control Adapter – 6720884375 (2019/07)
Table of contents
1Safety instructions
The maximum power consumption of the connected
components and assemblies must not exceed the power output
stated in the specifications for this module.
• Avoid high ambient temperatures ( table 2).
• Avoid moisture and a dusty atmosphere.
• Prevent short circuit or damage to the product.
• Before starting the installation, switch off the boiler mains
voltage.
• Only use the provided cables.
• Only clean the product with a dry cloth.
• Incorrect connection of this product can cause damage to
the unit. The unit must therefore only be installed by an
approved contractor.
• Depending on which signal is connected to the potential
contact, there is a danger of electric shock.
2Product Information
This product provides communication between a boiler without
an EMS function (Energy Management System) and:
• a thermostat with an EMS interface,
•a function module.
This product converts the following protocols to EMS and
viceversa:
• iRT (Intelligent Room Thermostat) for UBA (universal
burner control unit) 1.5,
• OpenTherm®, version 4.0 or higher,
• zero volt on-off switching contact.
Functional capability can be lost, if protocols are converted.
This product can also be used to increase the electrical output
of an EMS/iRT bus.
The standard delivery consists of ( fig. 1):
[1] EasyControl adaptor
[2] screw with rawl plug (2x)
[3] technical documentation
[4] power adaptor
This product has the following connection possibilities
( fig. 2):
[1] room thermostat
1)
[2] function module
[3] mains voltage
[4] power adaptor
[5] EasyControl adaptor
[6] zero volt contact
[7] function module
[8] other units
[9] EMS or iRT or OpenTherm bus or on-off
[10] boiler
This product has a warranty period of 2 years.
This product is in accordance in design and operation with the
European Directives and the supplementary national
requirements.
The conformity is indicated by the CE mark. You can ask for a
copy of the declaration of conformity for this product. For this
see the contact address on the back cover of these
instructions.
3 Environmental protection/disposal
Environmental protection is a key company principle for the
Bosch Group. Product quality, economical profitability and
environmental protection are equally important to us. We
strictly adhere to environmental laws and rules. To protect the
environment, we adapt, subject to economical considerations,
the best possible technology and materials.
Packaging
In our packaging, we consider all country specific recycling
systems to guarantee optimal recycling. All of our packaging
materials are environmentally friendly and recyclable.
Old electrical and electronic appliances
Electrical or electronic devices that are no longer
serviceable must be collected separately and sent
for environmentally compatible recycling (in
accordance with the European Waste Electrical
and Electronic Equipment Directive).
1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
2 Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . .21
3 Environmental protection/disposal . . . . . . . . . . . . . .21
4 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . .22
6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
7 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
8 Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
1) This product is compatible with Bosch brand, Buderus
brand and Worcester smart temperature controllers.
