EURO • Printed in USA • BA 2 610 907 617 • GBM 13 HRE • GB • OSW 04/01
English - 1
1 Ring gear drill chuck
2 Auxiliary handle
3 Lock-on button
4 On/Off switch
5 Rotational direction switch
6 Drill chuck key
7 Screwdriver attachment (bit)*
8 Bit holder*
9 Locking screw
10 Allen key*
*Optional accessories
*Not all of the accessories illustrated or described are
included as standard delivery.
The machine is intended drilling in wood,
metal, ceramic and plastic. Machines with
electronic control and right/left rotation are
also suitable for screwing and thread cutting.
Working safely with this ma-
chine is possible only when
the operating and safety infor-
mation are read completely
and the instructions con-
tained therein are strictly fol-
lowed. In addition, the general
safety instructions in the en-
closed booklet must be fol-
lowed. Before using for the
first time, ask for a practical
demonstration.
If the mains cable is damaged or
cut through while working, do not
touch the cable but immediately
pull the mains plug. Never use
the machine with a damaged ca-
ble.
For long hair, wear hair protec-
tion. Work only with closely fitting
clothes.
Wear ear protection.
Wear safety goggles.
■ Connect machines that are used in the open
via a residual current device (RCD) with an
actuating current of 30 mA maximum. Use
only extension cables that are approved for
outdoor use.
■ Insert the mains plug only when the ma-
chine is switched off.
■ Always direct the cable to the rear away
from the machine.
■ When drilling use the auxiliary handle 2.
■ Hold tools by insulated gripping sur-
faces when performing an operation
where the cutting tool may contact hid-
den wiring or its own cord.
Contact with a “live” wire will make exposed
metal parts of the tool “live” and shock the
operator.
■ If the drilling tool jams it will cause the tool
to jolt. If this occurs switch the tool off imme-
diately.
■ When working with the machine, always
hold it firmly with both hands and provide for
a secure stance.
■ Be careful when screwing in long screws;
danger of sliding off.
Tool Specifications
Drill GBM 13 HRE
Part number 0 601 049 6..
Rated power 550 W
Output power 285 W
No-load speed
Rated speed 0–380 rpm
Torque 60 Nm
Drill chuck clamping range 1/2" (13 mm)
Drill dia. steel 1/2" (13 mm)
Drill dia. wood 1 1/2" (40 mm)
Weight approx. 2.1 kg
Safety class / II
Machine Elements
Intended Use
For Your Safety
2 610 907 617.book Seite 1 Montag, 7. Mai 2001 12:53 12
10 • 2 610 907 617 • TMS • 27.04.01
0 – 550 rpm
