-15-
Store and transport the
tool only in the supplied
protective case.
Keep the tool clean at all times.
Do not immerse the tool into water or
other fluids.
Wipe off debris using a moist and soft cloth.
Do not use any cleaning agents or solvents.
Regularly clean the surfaces at the exit
opening of the laser in particular, and pay
attention to any fluff of fibers.
If the tool should fail despite the care taken
in manufacturing and testing procedures,
repair should be carried out by an
authorized after-sales service center for
Bosch power tools.
In all correspondence and spare parts
orders, please always include the 10-digit
article number given on the type plate of the
tool.
In case of repairs, send in the tool packed in
its protective case.
ENVIRONMENT PROTECTION
Recycle raw materials & batteries
instead of disposing of waste. The
unit, accessories, packaging &
used batteries should be sorted for
environmentally friendly recycling in accordance
with the latest regulations.
Maintenance and Service
Subject to change without notice.
Buzzer Volume Between 75 dB(A) and 85 dB(A) at 3 ft (1m)
Readout: LCD, front and rear windows.
Bright green LED on switch pad to indicate long range
mode.
Buzzer gives audible indication of detection and switch
pad operation.
Buzzer volume and feature is switch pad selectable.
Auto Shutoff 5 minutes after last detect or last button press.
Buzzer beeps once on power off.
Battery Type 2 x AA alkaline cells
Battery Life >30 hours of continuous operation
Low Battery Warning Indicator on LCD. At least 3 hours of low battery warning.
IP Rating IP55
Bracket Mount M6
Operating Temperature 14° F to 122° F (-10° C to 50° C)
Dimensions 6.6” H x 3” W x 1” D (169mm x 76mm x 25mm)
Bright Light Can achieve 265 ft (80 m) in 0 degree orientation
(X-Axis) to GLL 150 E providing direct sunlight does not
fall on the detector window, < 35kLux.
Florescent Light No false detects at any distance from a florescent light or
strobes.
Receive Angle ±30 degrees
!
WARNING
