After use, place down the glue pen in a safe manner and
allow it to cool down completely before packing it
away. The hot nozzle can cause damage and/or burns.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally oc-
curs, flush with water. If liquid contacts eyes, addition-
ally seek medical help. Liquid ejected from the battery
may cause irritations or burns.
Safety Warnings for Battery Chargers
Keep the battery charger away from rain or mois-
ture. Penetration of water in the battery charger in-
creases the risk of an electric shock.
Only charge Bosch lithium ion batteries or lithium ion
batteries installed in Bosch products. The battery volt-
age must match the battery charging voltage of the
charger. Otherwise there is danger of fire and explosion.
Keep the battery charger clean. Contamination can lead
to danger of an electric shock.
In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Product Description and Specifica-
tions
Intended Use
The glue pen is intended for solvent-free bonding of e. g., pa-
per, cardboard, cork, wood, leather, textiles, foam, plastics,
(except PE, PP, PTFE, Styropor® and soft PVC), ceramics,
porcelain, metal, glass and stone.
Product Features
The numbering of the product features refers to the illustra-
tion of the glue pen on the graphics pages.
1 Nozzle
2 Silicone cap
3 Feed trigger
4 On/Off button
5 LED indicator
6 Glue stick*
7 Glue stick opening
8 Socket for charge connector
9 Plug connector for charger
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Assembly
Battery Charging (see figure A)
Observe the mains voltage! The voltage of the power
supply must correspond with the data given on the name-
plate of the battery charger. Battery chargers marked with
230 V can also be operated with 220 V.
The battery is supplied partially charged.
To ensure full battery capacity, completely charge the battery
(at least 2 –3 hours) before using for the first time.
The glue pen cannot be used during the charging procedure;
it is not defective, when it does not function during the charg-
ing procedure.
The Lithium-Ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not damage the battery.
The “Electronic Cell Protection (ECP)” protects the lithium ion
battery against deep discharging. When the battery is dis-
charged, the glue pen is switched off by a protective circuit:
The glue is no longer heated.
Cordless glue pen GluePen
Article number
3 603 BA2 0..
Heating time
sapprox. 15
Gluing temperature
°C approx. 170
Glue stick, diameter
mm Ø 7
Glue stick, length
mm 150
Weight according to
EPTA-Procedure 01/2003
kg 0.1
Battery
Li-Ion
Rated voltage
V= 3.6
Capacity
Ah 1.5
Number of battery cells
1
Operating duration per bat-
tery charge (according to
Bosch testing procedures)
min approx. 30
(corresponds with ap-
prox. 6 glue sticks)
Battery Charger
Article number 2 609 120 4..
Charging time
h 3.0 –4.0
Output voltage
V= 5
Charging current
mA 500
Allowable charging tempera-
ture range
°C +5 ... +40
Weight according to
EPTA-Procedure 01/2003
kg 0.1
Protection class
/II
