Figure
● Push the flexible tube adapter into the air intake opening on the
appliance. Check for correct seating – the moulded hook on the tube
adapter must fit into the recess in the air intake opening and audibly click
into place.
Figure
● Push the handle into the telescopic tube until it engages. To release the
connection, squeeze the locking collar and pull out the handle.
Figure
● Push the telescopic tube into the connecting piece of the floor tool until it
engages. Press the locking collar and pull out the telescopic tube to release
the connection.
2
3
1
5
Starting up
1
2
Click!
3
