Technical Data
Product Features
The numbering of the product features refers to the
illustration of the power tool on the graphics page.
1 Dust protection cap
2 Locking sleeve
3 Chisel adjustment ring (Vario-lock)
4 On/Off switch
5 Dial control for preselection of impact rate
6 Service indicator
7 Auxiliary handle
8 Knurled nut for auxiliary handle
Not all of the accessories illustrated or described are
included as standard delivery.
Assembly
Auxiliary Handle
Operate your power tool only with the auxiliary
handle 7.
The auxiliary handle 7 can be set to any position for a
secure and low-fatigue working posture.
Loosen the knurled nut 8, rotate the auxiliary handle 7
around the axis of the power tool to the required posi-
tion and tighten the knurled nut 8 again.
The auxiliary handle 7 can be mounted to a different
position. For this, completely unscrew the knurled nut 8
and then pull out the hexagon bolt upward. Pull off the
auxiliary handle 7 to the side and turn around the
remaining clamping element by 180°. Mount the auxil-
iary handle 7 in reverse order.
Changing the Tool
Before any work on the power tool itself, pull the
mains plug.
With the SDS-max tool holder, simpler and easier tool
changing is possible without additional aids.
The dust protection cap 1 largely prevents the entry of
drilling dust into the tool holder during operation. When
inserting the tool, take care that the dust protection
cap 1 is not damaged.
A damaged dust protection cap should be
changed immediately. We recommend having this
carried out by an after-sales service.
Inserting (see figure A)
Clean and lightly grease the shank end of the tool.
Insert the tool in a twisting manner into the tool holder
until it latches itself.
Check the latching by pulling the tool.
Removing (see figure B)
Push back the locking sleeve 2 and remove the tool.
Demolition Hammer GSH 11 E
PROFESSIONAL
Article number 0 611 316 7..
Rated power input W 1500
Impact rate bpm 900–1890
Impact energy per stroke J 6–25
Chisel positions 12
Chiselling capacity in
concrete of medium
hardness kg/h 490
Tool holder SDS-max
Lubrication Central permanent
lubrication
Weight according to
EPTA-Procedure
01/2003
kg 10.1
Protection class
/II
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltages and models for specific coun-
tries, these values can vary.
Please observe the article number on the type plate of your
power tool. The trade names of individual tools may vary.
