16 | English
fire and electric shock. Damaging gas lines can lead to ex-
plosion. Breaking water pipes causes property damage.
u Always wait until the power tool has come to a com-
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
u In case of damage and improper use of the battery, va-
pours may be emitted. The battery can set alight or ex-
plode. Ensure the area is well ventilated and seek medical
attention should you experience any adverse effects. The
vapours may irritate the respiratory system.
u Do not open the battery. There is a risk of short-circuit-
ing.
u The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
u Only use the battery with products from the manufac-
turer. This is the only way in which you can protect the
battery against dangerous overload.
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture. There is a risk of explosion and
short-circuiting.
u Switch the power tool off immediately if the applica-
tion tool becomes blocked. Be prepared for high
torque reactions which cause kickback. The applica-
tion tool becomes blocked when it becomes jammed in
the workpiece or when the power tool becomes over-
loaded.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for driving and loosening screws
and for drilling in wood, metal, ceramic and plastic. The GSB
is also designed for impact drilling in brick, concrete and
stone.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Tool holder
(2)
Keyless chuck
(3)
Torque presetting ring
(4)
Operating mode presetting ring
(GSB 14.4/18 VE-2-LI)
(5)
Gear selector switch
(6)
Wing bolt for depth stop adjustment
(7)
Auxiliary handle with depth stop
(8)
Handle (insulated gripping surface)
(9)
Battery
A)
(10)
Depth stop
(11)
Battery release button
(12)
Worklight
(13)
Intermediate piece of auxiliary handle
(14)
On/off switch
(15)
Battery charge indicator button
(16)
Battery charge indicator
(17)
Rotational direction switch
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Cordless drill/driver GSR 14.4 VE-2-LI GSR 18 VE-2-LI GSB 14.4 VE-2-LI GSB 18 VE-2-LI
Article number
3 601 JD9 0.. 3 601 JD9 1.. 3 601 JD9 2.. 3 601 JD9 3..
Rated voltage V= 14.4 18 14.4 18
No-load speed
A)
– First gear min
-1
0–400 0–400 0–440 0–440
– Second gear min
-1
0–1700 0–1700 0–1850 0–1850
Impact rate
A)
min
-1
– – 0–27,750 0–27,750
Max. torque, hard/soft screw-
driving application according to
ISO 5393
A)
Nm 75/40 80/47 80/36 85/42
Max. drilling diameter
– Wood mm 45 50 40 45
– Steel mm 13 13 13 13
– Masonry mm − − 14 16
1 609 92A 4V5 | (13.11.2019) Bosch Power Tools

Bosch GSR Series Specifications

General

Chuck Type	Keyless
Battery Type	Li-Ion
Power Source	Cordless
Battery Voltage	12V or 18V (depending on model)
Chuck Size	10mm or 13mm (depending on model)
Torque Settings	20+1 (depending on model)
