English - 1
The numbering of the machine elements refers to
the illustration of the machine on the graphics
page.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
1 Gripping surface
2 Thumb wheel for oscillating rate selection
(GSS 230 AE/GSS 280 AE)
3 On/Off switch
4 Lock-on button for On/Off switch
5 Dust box (micro filtersystem)*
6 Clamping lever
7 Sanding plate
8 Clamping strip
9 Allen screw
10 Auxiliary handle
11 Allen key
12 Sanding sheet (Velcro attachment)*
13 Sanding sheet (without Velcro attachment)*
14 Vacuum hose*
15 Extraction adapter*
16 Outlet piece
17 Plastic slider
18 Dust bag*
19 Holder for dust box*
20 Latching lever*
21 Filter element (micro filtersystem)*
22 Perforating tool*
23 Sanding plate screw
24 Sanding plate, thin, extended*
25 Sanding sheet, extended*
26 Screw for extended sanding plate*
27 Triangular sanding sheet*
28 Triangular sanding plate, extended*
* Not all of the accessories illustrated or described are
included as standard delivery.
Tool Specifications
Orbital sander GSS ...
PROFESSIONAL
230 A 230 AE 230 AE 280 A 280 AE 280 AE
Article number 0 601 … 292 0.. … 292 7.. … 292 6.. … 293 0.. … 293 7.. … 293 6..
Dust box included
in delivery scope
– – ● – – ●
Rated input power [W] 300 300 300 330 330 330
Output power [W] 90 90 90 100 100 100
Oscillating
rate selection
– ● ● – ● ●
Orbit frequency [opm] 22 000 11 000 –
22 000
11 000 –
22 000
22 000 11 000 –
22 000
11 000 –
22 000
No-load speed [rpm] 11 000 5 500 –
11 000
5 500 –
11 000
11 000 5 500 –
11 000
5 500 –
11 000
Orbit diameter [mm] 2.4 2.4 2.4 2.4 2.4 2.4
Sanding plate [mm] 92 x 182 92 x 182 92 x 182 114 x 226 114 x 226 114 x 226
Sanding sheet:
Velcro attachment [mm] 93 x 185 93 x 185 93 x 185 115 x 230 115 x 230 115 x 230
Clamping attachment [mm] 93 x 230 93 x 230 93 x 230 115 x 280 115 x 280 115 x 280
Weight according
to EPTA-Procedure
01/2003
[kg] 2.3 2.3 2.3 2.6 2.6 2.6
Protection class / II / II / II / II / II / II
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltages and models for specific countries, these
values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Machine Elements
2 609 932 440.book Seite 1 Montag, 13. Dezember 2004 11:06 11
11 • 2 609 932 440 • TMS • 03.12.04

Bosch GSS 230 A PROFESSIONAL Specifications

General

Power input	190 W
Sanding surface	92 x 182 mm
Sanding sheet size	93 x 230 mm
Sanding plate size	92 x 182 mm
Cable length	2.5 m
Dust extraction	Yes
No-load speed	12, 000 opm
Oscillating circuit diameter	2 mm
Orbital stroke rate	24, 000 opm
