Information about the appliance
9
Greenstar FS/Combi FS – 6 720 810 590 (2020/04)
Fig. 5 Dimensions and minimum clearances (front, rear, side view)
[1] 45
3
/
4
” - (1163mm)
[2] 41
15
/
16
” - (1065mm)
[3] 27
9
/
16
” - (700mm)
[4] **24” - (600mm)
[5] 7
7
/
8
” - (200mm)
[6] ***≥ 2
3
/
4
” - (70mm)
[7] *4” - (102mm)
[8] *4” - (102mm)
[9] 41” - (1042mm)
[10] 18
3
/
8
” - (467mm)
[11] 19
9
/
16
” - (497mm)
(*) Zero clearance from combustibles permitted, but 4”
(102mm) recommended for serviceability
(**) 1” (25mm) distance to door, if mounted inside a closet with
24” (600mm) in front of boiler for serviceability
(***) 12” (300mm) recommended distance behind the boiler for
serviceability
6720810590-08.1Wo
1
2
3
6
4
5
7
8
9
10
11
