Bosch Kiox 300 - Inserting the Locking Plate

English – 16
To remove the display(1), pull the display(1) towards you ❶ until you are
able to lift off the display(1) ❷.
A retaining strap can be secured to the bridge(10).
Note: The eBike system switches off if you are traveling slower than 3km/h
and take the on-board computer out of the holder. This does not apply to
eBikes with a support up to 45km/h.
Inserting the Locking Plate (seefigureB)
(9)
(3)
(8)
B
(5)
Note: Depending on the design/installation of the display mount, it may be
the case that the removal blockercannot be used. The display must be in-
stalled here.
Insert the locking plate(3) into the adapter shell(5) from below until you
hear the locking plate(3) click into place.
Bosch eBike Systems 0 275 U07 3en | (01.02.2022)
