Bosch LBB 1950/10 - Technical Specifications and Ordering; Product Specifications; Ordering Information and Accessories; Installation and Configuration Notes

Installation/Configuration Notes
Circuit diagram
Parts Included
Quantit
y
Component
1 LBB 1950/10 PLENA Tabletop Unidirectional Condenser
Microphone
1 DIN to XLR adapter
Technical Specifications
Electrical
Phantom power supply
Voltage range 12 to 48 V
Current consumption <8 mA
Performance
Sensitivity 0.7 mV @ 85 dB SPL (2 mV/Pa)
Maximum input sound level 110 dB SPL
Distortion <0.6% (maximum input)
Input noise level (equiv.) 28 dB SPLA (S/N 66 dBA ref. 1 Pa)
Frequency response 100 Hz to 16 kHz
Output impedance 200 ohm
Mechanical
Base dimensions (H x W x D) 40 x 100 x 235 mm
(1.57 x 3.97 x 9.25 in)
Weight Approx. 1 kg (2.2 lb)
Color Charcoal with silver
Stem length with mic 390 mm (15.35 in)
Cable length 2 m (6.56 ft)
Environmental
Operating temperature -10 ºC to +55 ºC (14 ºF to +131 ºF)
Storage temperature -40 ºC to +70 ºC (-40 ºF to
+158 ºF)
Relative humidity <95%
Ordering Information
LBB 1950/10 Plena Tabletop Unidirectional Condenser
Microphone
tabletop unidirectional condenser microphone on a
flexible stem.
Order number LBB1950/10
Accessories
LBC 1102/02 Cable Transformer
for galvanic separation
Order number LBC1102/02
LBC 1080/00 Microphone Cable
length 100 m; 2 x 0.13 mm
2
Order number LBC1080/00
LBC 1082/00 Microphone Cable
length 100 m; 2 x 0.75 mm
2
Order number LBC1082/00
LBC 1081/00 Microphone Cable
length 100 m; 4 x 0.14 mm
2
Order number LBC1081/00
2 | LBB 1950/10 Plena Tabletop Unidirectional Condenser Microphone
