Bosch Security Systems | 2009-01
LC1 Modular Ceiling Loudspeaker Range | Installation and User Instructions | en | 20
4 Accessories
4.1 Technical Specifications
LC1-MFD
LC1-CMR / LC1-CBB
LC1-MMSB
LC1-CSMB LC1-MSK LM1-TB LC1-PIB
Surface Mounting box Metal Suspension Kit Tile Bridge/C-ring Pilot Tone indication board
220 x 128 mm 250 x 30 mm 20 x 30 mm
(8.67 x 5.04 in) (9.85 x 1.18 in) (0.78 x 1.18 in)
n.a. n.a. n.a.
ABS Steel Steel n.a.
White (RAL 9010) Zinc Plated Zinc Plated n.a.
690 g (1.52 lb) 174 g (0.38 lb) 939 g (2.07 lb) 3 g (0.006 lb)
Technical Specifications LC1-MMSB LC1-CMR LC1- CBB LC1-MFD
Description Mounting support bracket Ceiling mounting ring Back box Metal Fire-dome
Dimensions 215 x 125 x 56 mm 215 x 67 mm 196 x 70 mm 215 x 155 mm
(8.47 x 4.92 x 2.2 in) (8.47 x 2.64 in) (7.72 x 2.75 in) (8.47 x 6.1 in)
Mounting cut-out 190 mm (7.48 in) 200 mm (7.88 in) n.a. 190 mm (7.48 in)
Material Steel ABS ABS Steel
Color Zinc Plated White (RAL 9010) White (RAL 9010) Flame red (RAL 3000)
Weight 320 g (0.70 lb) 210 g (0.46 lb) 174 g (0.38 lb) 1 kg (2.20 lb)
Technical Specifications
Description
Mechanical
Dimensions
Mounting cut-out
Material
Color
Weight
