4 en | Installation LC3 Ceiling Loudspeaker Range
IN-LC3-UC06 | V1.0 | 2011.06 Installation Note Bosch Security Systems B.V.
7: Connection LC3-UC06 + LC3-CBB (optional) 8: LC3-UC06 + LC3-CBB (optional)
910
Dimensions LC3-UC06 + LC3-CBB (optional)
Click
153.5 mm / 6.04"
163 mm / 6.41"
162 mm / 6.37"
180 mm / 7.08"
110.6 mm / 4.35"
68.8 mm / 2.70"
11 mm / 0.43"
2 x 11 mm / 0.43"
2 x 20.5 mm / 0.80"
