Bosch LC3-UC06 - Installation

LC3 Ceiling Loudspeaker Range Installation | en 3
Bosch Security Systems B.V. Installation Note IN-LC3-UC06 | V1.0 | 2011.06
1 Installation
1: Ceiling cut-out template 2
34
5: Connection LC3-UC06-LZ (4Ω) 6: Connection LC3-UC06 (100 V)
167 mm / 6.57"
167 mm / 6.57"
min. 5 mm / 0.19"
max. 25 mm / 0.98"
C6W3W1.5W
0
100V
4
