Bosch LC3-UC06E - Installation

Installation
Fig. 1 Fig. 2
167 mm / 6.57"
min. 5 mm / 0.19"
max. 25 mm / 0.98"
Fig. 3 Fig. 4 LC3‑UC06E and LC3‑CBB
Fig. 5 Fig. 6
1
Ceiling Loudspeaker Installation | en 3
Bosch Security Systems B.V. Installation note 2013.11 | V1.4 |
