Bosch LR 1 - Page 8

English | 23
Bosch Power Tools 2 610 A12 917 | (19.1.10)
LR 1/LR 1 G
Working range
1)
with rotational
laser level:
–GRL250HV
– GRL 300 HV/HVG
–GRL400H
125 m
150 m
200 m
Receiving angle
120°
Receivable rotation speed
>200 min
-1
Measuring accuracy
2)
– “Fine” adjustment
– “Medium” adjustment
± 1mm
± 3mm
Operating temperature
– 10 °C ... +50 °C
Storage temperature
– 20 °C ... +70 °C
Battery
1x9V 6LR61
Operating life time, approx.
50 h
Weight according to
EPTA-Procedure 01/2003
0.36 kg
Dimensions
148 x 73 x 30 mm
Degree of protection
IP 65 (dust-proof and
protected against powerful
water jets)
1) The working range (radius) can be reduced due to unfavourable ambient
conditions (e.g. direct sunlight).
2) depends on clearance between laser receiver and rotational laser level
OBJ_BUCH-780-003.book Page 23 Tuesday, January 19, 2010 10:56 AM
