Sealed burners
Your new cooktop has sealed gas burners. There are no
burner parts under the cooktop to clean, disassemble or
adjust. Your cooktop has three different burner sizes:
small, medium, and large.
Burner Cap and Burner Base Placement
9 WARNING
To prevent flare-ups, do not use the cooktop without
all burner caps and all burner grates properly
positioned.
9 WARNING
To prevent burns, do not touch burner caps or
grates while hot. Turn the cooktop off and allow the
entire cooktop to cool.
The burner caps must be properly placed for the cooktop
to function properly. If the burner cap is not properly
placed, one or more of the following problems may
occur:
▯ Burner flames are too high.
▯ Burner flames extend too far on sides.
▯ Stainless steel discolors.
▯ Burners do not ignite.
▯ Burner flames light unevenly.
▯ Burner emits gas odor.
Correct Burner Cap Placement
Incorrect Burner Cap Placement
A Igniter
B Burner Cap
C Burner Base
D Jet Holder
E Panhead Screw
%
&
$
'
(
