9
NGM8056UC
*See section OptiSim® Burner Cap Placement and
OptiSim® Burner Cap Installation for further information.
1 Left front burner (10,000 BTU/ 2.93 kW)
2 Left rear burner (5,500 BTU/ 1.61 kW) *OPTISIM® feature
3 Center burner (19,000 BTU/ 5.57kW)
4 Right rear burner (10,000 BTU/ 2.93kW)
5 Right front burner (5,500 BTU/ 1.61kW)
6 Burner “On” indicator light
7 Serial Number/Data Plate location
(right front underneath)



