8. INSTALLATION
Now connect the two plugs remaining on the chip to the engine, respecting the correct posi-
tion of the colors (display RED WIRE and speed sensor WHITE WIRE get to the RIGHT), push
the connectors rmly to the end; CAUTION: WRONG CONNECTION LEADS TO SHORTCIRCUIT,
DAMAGES NOT COVERED BY WARRANTY!
8
9
Possibly arrange the cables with electrician clamps paying attention that there are no wires in
correspondence with holes where cover’s screws are.
