Interconnections
• 2 x RJ45 jacks
Certifications and approvals
Safety acc. to EN 60065
Immunity acc. to EN 55103-2
Emission acc. to EN 55103-1
Region Certification
Europe CE
Parts included
Quantity Components
1 PLE-2CS Plena two-zone call station
1 Cable terminated with a lockable CAT-5 connector
Technical specifications
Electrical
Voltage range 24 VDC supplied by PLE mixer amplifier
or mixer
Current consumption <30 mA
Performance
Nominal sensitivity 85 dB SPL (gain preset 0 dB)
Nominal output level 700 mV
Input sound level (max) 110 dB SPL
Gain preset -15 / 0 / +6 dB
Limiter threshold 2 V
Compression ratio limiter 1:20
Distortion <0.6% (maximum input)
Input noise level (equiv.) 25 dB SPLA
Frequency response 100 Hz to 16 kHz
Speech filter -3 dB at 315 Hz, high-pass, 6 dB/oct
Output impedance 200 ohm
Selections
Chimes 6
Mechanical
Base dimensions
(H x W x D)
without microphone
40 x 100 x 235 mm (1.57 x 3.97 x
9.25 in)
Stem length with
microphone
390 mm (15.35 in)
Cable length 5 m (16.4 ft)
Weight Approx. 1 kg (2.2 lb)
Mounting Standalone
Color Charcoal with silver
Environmental
Operating temperature -10 ºC to +45 ºC (14 ºF to +113 ºF)
Storage temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF)
Relative humidity <95%
Ordering information
PLE‑2CS Plena Two-zone Call Station
metal base design, a flexible microphone stem with a
unidirectional condenser microphone and zone
selection
Order number PLE-2CS
2 | PLE‑2CS Plena Two-zone Call Station
