f Do not operate the measuring tool in explosive environ-
ments, such as in the presence of flammable liquids, gas-
es or dusts. Sparks can be created in the measuring tool
which may ignite the dust or fumes.
Keep the measuring tool away from cardiac
pacemakers. The magnets 8 generate a field that
can impair the function of cardiac pacemakers.
f Keep the measuring tool away from magnetic data medi-
um and magnetically-sensitive equipment. The effect of
the magnets 8 can lead to irreversible data loss.
Functional Description
Intended Use
The measuring tool is intended for horizontal and diagonal
alignment of tiles and laminate flooring panels.
The measuring tool 3 603 F64 000 is suitable for operation ex-
clusively in enclosed work sites.
Product Features
The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.
1 On/Off switch
2 Exit opening for laser beam
3 Spirit levels for vertical and horizontal alignment
4 Laser warning label
5 Spirit level for diagonal alignment
6 90° scale with 5° graduation
7 T-edge for alignment
8 Magnets
9 Battery lid
10 Bottom plate
11 L-edge for alignment
12 Latch of battery lid
13 Wall holder
14 Laser viewing glasses*
* The accessories illustrated or described are not included as stand-
ard delivery.
