16 | English
1 609 92A 4BL | (01.10.2018) Bosch Power Tools
u Hold the power tool firmly with both hands and make
sure you have a stable footing. The power tool can be
more securely guided with both hands.
u When changing the application tool, wear protective
gloves.Application tools can become hot when used for
prolonged periods of time.
u Do not scrape any dampened materials (e.g. wallpa-
per) or on damp surfaces. Water entering a power tool
increases the risk of electric shock.
u Do not treat the surface you will be working on with
any fluids that contain solvents. Poisonous vapours
may develop due to the materials heating up when being
scraped.
u Take particular care when handling scrapers and
blades. The application tools are very sharp. Danger of in-
jury.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Keep the magnet away from cardiac pace-
makers. The magnet (7) generates a field
that can impair the function of pacemakers.
u Keep the power tool away from magnetic data carriers
and magnetically sensitive equipment. The effect of
the magnet (7) can lead to irreversible data loss.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is intended for sawing and cutting wood-
based materials, plastic, plasterboard, non-ferrous metals
and mounting elements (e.g. nails, clamps). It is also suit-
able for working on soft wall tiles and for dry sanding and
scraping of small areas. It is ideal for working close to edges
and flush with surfaces.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
On/off switch
(2)
Orbital stroke rate preselection thumbwheel
(3)
Ventilation slots
(4)
Handle (insulated gripping surface)
(5)
Thread for auxiliary handle
(6)
Tool holder
(7)
Magnet
(8)
Plunge cut saw blade
A)
(9)
Clamping bolt
(10)
Hex key
(11)
Sanding plate
A)
(12)
Sanding sheet
A)
(13)
Depth stop
A)
(14)
Segment saw blade
A)
(15)
Clamping lever for dust extraction system
A)
(16)
Dust extraction outlet
A)
(17)
Dust extraction system
A)
(18)
Dust extraction hose
A)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Multifunction tool PMF 220 CE
PMF 2000 CE
Article number
3603A020..
Orbital stroke rate preselec-
tion
●
Constant electronic control ●
Soft start ●
Rated power input W 220
Power output W 130
No-load speed n
0
min
−1
15000–20000
Oscillation angle on left/
right
° 1.4
Weight according to
EPTA-Procedure 01:2014
kg 1.1
Protection class / II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/Vibration Information
Noise emission values determined according to
EN62841‑2‑4.
Typically, the A-weighted noise level of the power tool is:
84dB(A); sound power level 95dB(A). Uncertainty K=3dB.
Wear hearing protection
