English6
Bosch eBike Systems 0 275 U07 XPX | (8.5.17)
Product Description and Specifications
Product Features
All representations of bike components, with the exception
of the battery packs and their holders, are schematic and
can deviate from your eBike.
1 Holder for the rack-type battery pack
2 Rack-type battery pack
3 Operation and charge-control indicator
4 On/Off button
5 Key for the battery pack lock
6 Battery pack lock
7 Upper holder for the standard battery pack
8 Standard battery pack
9 Bottom holder for the standard battery pack
10 Cover lid (supplied only on eBikes with
2 battery packs)
11 Battery charger
12 Socket for charge connector
13 Charge socket cover
1
11
9
12
13
8
6
5
5
7
2
13
12
4
3
3
4
6
10
OBJ_BUCH-2451-004.book Page 6 Monday, May 8, 2017 9:52 AM
