English | 11
Bosch Power Tools 1 609 929 M91 | (17.10.11)
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 70 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Drilling into metal: a
h
<2.5m/s
2
, K=1.5 m/s
2
,
Screwdriving: a
h
<2.5m/s
2
, K=1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
11.10.2011
Assembly
Battery Charging
A battery that is new or has not been used for a longer period
does not develop its full capacity until after approx. 5 charg-
ing/discharging cycles.
To remove the battery 7 press the unlocking buttons 6 and
pull out the battery downwards. Do not exert any force.
The battery is equipped with a NTC temperature control
which allows charging only within a temperature range of be-
tween 0 °C and 45 °C. A long battery service life is achieved
in this manner.
A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.
Observe the notes for disposal.
Changing the Tool (see figure A)
f Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating
the On/Off switch.
Hold the rear sleeve 3 of the keyless chuck 1 tight and turn the
front sleeve 2 in rotation direction n, until the tool can be in-
serted. Insert the tool.
Firmly tighten the collar of the keyless chuck 1 by hand in ro-
tation direction o until the locking action (“click”) is no longer
heard. This automatically locks the chuck.
The locking is released again to remove the tool when the
front sleeve 2 is turned in the opposite direction.
Cordless Drill/Driver PSR 960 PSR 1200
Article number
0 603 944 6.. 0 603 944 5..
Rated voltage
V= 9.6 12
No-load speed
min
-1
0–550 0–700
Maximum torque, hard screwdriving application according to ISO 5393
Nm 12 15
Max. drilling dia.
– Steel
– Wood
mm
mm
8
14
10
20
Max. screw dia. mm 6 8
Chuck clamping range
mm 1 – 10 1–10
Drill spindle thread
3/8" 3/8"
Weight according to EPTA-Procedure 01/2003
kg 1.3 1.4
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Engineering Director
PT/ESI
OBJ_BUCH-572-004.book Page 11 Monday, October 17, 2011 7:32 AM
