1 609 92A 20W | (18.1.16) Bosch Power Tools
34 | English
When changing the application tool, wear safety goggles. Do not
stare directly into the tool holder. When changing the tool insert, it can
be thrown out toward the front.
Only insert one screwdriver bit per chamber into the bit magazine.
Use only short standard screwdriver bits. Longer screwdriver bits can-
not be loaded into the bit magazine.
– Turn the bit magazine 11 until an empty chamber can be seen in viewing
window 3.
– Push the sliding switch 7 toward the front.
– Insert the screwdriver bit 1 directly into the tool holder 2.
– Push the sliding switch 7 to the rear to load the screwdriver bit 1 into bit
magazine 11.
– As soon as you push the sliding switch 7 to the rear or actuate the On/Off
switch 10 when in the rear position, the bit magazine 11 is illuminated for
approx. 20 seconds.
Changing the Tool (see figure D)
When changing the application tool, wear safety goggles. Do not
stare directly into the tool holder. When changing the tool insert, it can
be thrown out toward the front.
– Turn the bit magazine 11 until the desired screwdriver bit 1 can be seen
in viewing window 3.
– Push the sliding switch 7 toward the front.
Operation
Starting Operation
Reversing the rotational direction (see figure E)
The rotational direction switch
8
is used to reverse the rotational direction of
the machine. However, this is not possible with the On/Off switch
10
actuated.
Right rotation: For driving in screws, push the rotational direction switch 8
left to the stop.
The indicator for right rotation 4 lights up when the On/Off switch
10 is actuated and the motor is running.
OBJ_BUCH-1564-004.book Page 34 Monday, January 18, 2016 11:10 AM
