English | 9
Bosch Power Tools 1 609 929 W69 | (22.3.10)
en
Safety Notes
General Safety Rules
Read all warnings and instructions
provided with the tile cutter or the
sawing station.
Safety Warnings for Tile Cutters
f Wear protective gloves when cutting tiles.
Sharp edges develop on broken tiles and can
cause injuries to the operator.
f Use the tile cutter only for cutting the mate-
rials listed under Intended Use. Marble or
granite as well as tiles with a rough surface
structure and natural stone tiles cannot be
cut.
Functional Description
Intended Use
The tile cutter is intended for cutting ceramic
tiles to a maximum thickness of 10 mm.
Product Features
The numbering of the product features refers to
the illustrations on the graphics pages.
PTC 1
1 Tile cutter
2 Stop with scale
3 Break-off cones
PLS 300*
4 Locking knob for height adjustment
5 Guide rail
6 Locking lever of the guide rail
7 Bridge
8 Base unit
9 Locking knob for various mitre angles
(horizontal)
10 Angle indicator (horizontal)
*The product shown or described is not part of the
standard delivery scope.
Technical Data
Operation
Note: The tile cutter PTC 1 can be used both for
free-hand cuts as well as for cutting tiles in com-
bination with the sawing station PLS 300.
For precise working, mitre angles from maxi-
mum –45° to +45° can be set on the sawing sta-
tion.
Preparing for Operation (with PLS 300)
The stop 2 is supplied as two parts, folded to-
gether.
– Before using for the first time, put the two
parts of the stop 2 together, so that they can-
not be taken apart afterwards.
Lengthway Cuts (see figures A1 – A3)
– Loosen the locking knob 4 a few turns.
– Turn the locking lever 6 of the guide rail left-
ward and fold the guide rail 5 upward.
– Place stop 2 centred in the groove of bridge
7 and slide it flush into base unit 8.
– Mark the desired cutting line on the work-
piece.
– Place down the workpiece with the visible
side up, flat against the stop 2.
– Fold the guide rail 5 down and align the
workpiece cutting line to the scale of the
stop 2.
– Press down the guide rail 5 in the area of the
workpiece with your flat hand.
– Tighten the locking knob 4.
– Lock the guide rail 5 with locking lever 6.
Tile cutter PTC 1
Article number
3 603 M04 2..
Max. cutting height
mm 10
Max. cutting length for
crossway cuts (90°)
mm 340*
Mitre/Bevel Angle
Horizontal
° ± 45*
Weight according to
EPTA-Procedure 01/2003
kg 0.2
* only in combination with PLS 300
OBJ_BUCH-1220-001.book Page 9 Monday, March 22, 2010 11:39 AM
