Quiet Lawn Mower
Easi-lite 28 Easi-lite 30
Part number F016 700 1.. F016 702 0..
Rated power 1000 W 1000 W
Maximum
cutting width 28 cm 30 cm
Height of cut 20/30 mm 20/30 mm
Positions 2 2
Weight 4.6 kg 4.6 kg
Protection class /
II
/
II
Serial Number See rating details on
machine
This product is intended for domestic lawn mow-
ing.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is impor-
tant that you read these instructions carefully.
When fully assembled the machine weighs ap-
proximately 4.6 kg. If necessary, obtain assist-
ance to remove from packaging.
Carefully remove the machine from its packag-
ing and check that you have all the following
items:
– Lawnmower with handle assembly
– 1 Handle bottom
– 2 Bolts
– 2 Wing nuts
– 2 Pivot pins
– 2 Cable clips
– Operating instructions
When parts are missing or damaged, please contact
the consumer care hotline on (01895) 838782 for assist-
ance. We also have a network of Atco-Qualcast Ap-
proved Service Agents who you can contact for serv-
ice and advice both within and outside the period of
guarantee.
1
Switch lever
2
Safety button
3
Handle top
4
Mains plug**
5
Cable restraint**
6
Handle bottom
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Electrical Safety
Your machine is double insulated for safety and
requires no earth connection. The operating
Voltage is 230 V ac, 50 Hz. Only use an ap-
proved extension cable. Contact your service
agent for details.
Extension cords/leads should only be used if
they comply with H05VV-F or H05RN-F types.
It is recommended for increased electrical
safety to use a Residual Current Device (RCD)
with a tripping current of not more than 30 mA.
Always check your RCD every time you use it.
For Product not sold in GB:
WARNING: For safety, it is essential that the
mains plug
4
attached to the machine is fitted
to the power supply cable
10
as in figure
B
.
The couplings of connection leads must be pro-
tected against splashes and the coupling sock-
ets on the leads must be made of rubber or
coated with rubber.
Fixing means for the connection leads must be
used.
The connection lead must be inspected for signs
of damage at regular intervals and may only be
used if in perfect condition.
If the supply cord is damaged it must be re-
placed by a Atco-Qualcast approved service
agent.
Products sold in GB only:
Your mower is fitted
with an approved 13 A (BS1363/A) electric plug
and is protected by a 13 A fuse (ASTA Approved
to BS 1362).
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
For Your Safety
WARNING! SWITCH OFF, REMOVE PLUG FROM
MAINS BEFORE ADJUSTING, CLEANING OR IF CA-
BLE IS CUT, DAMAGED OR ENTANGLED.
THE BLADES CONTINUE TO ROTATE FOR A FEW
SECONDS AFTER THE MACHINE IS SWITCHED OFF.
CAUTION - DO NOT TOUCH ROTATING BLADES.
