Bosch Quigo Plus - Technical Specifications

20 | English
1 609 92A 1EE | (14.12.15) Bosch Power Tools
6 Battery lid
7 Laser warning label
8 Serial number
9 Laser target plate
10 Laser viewing glasses*
* The accessories illustrated or described are not included as standard delivery.
Technical Data
Cross-line Laser Quigo Plus
Article number
3 603 F63 6..
Working range, min.
1)
7m
Levelling Accuracy
–at0°
– at±4°
±0.8 mm/m
±1.0 mm/m
Self-levelling range, typically
±4°
Levelling duration, typically
6s
Operating temperature
+5 °C...+40 °C
Storage temperature
–20 °C...+70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
1) The working range can be decreased by unfavourable environmental conditions (e. g. direct
sun irradiation).
The measuring tool can be clearly identified with the serial number 8 on the type plate.
