Assembly
Inserting/Replacing the Batteries
Alkali-manganese batteries are recommended for the measuring tool.
To open the battery lid 6, press the latch 4 in the direction of the arrow and remove
the battery lid. Insert the batteries provided. Pay attention to the correct polarity
of the batteries according to the representation in the battery compartment.
If the batteries become weak, the laser lines will flash quickly for a few seconds.
Always replace all batteries at the same time. Only use batteries from one brand
and with the identical capacity.
 Remove the batteries from the measuring tool when not using it for
extended periods. When storing for extended periods, the batteries can
corrode and self-discharge.
C
6
1
Divergence
–Laser line
0.5 mrad (full angle)
Tripod mount
1/4"
Batteries
2x1.5VLR3(AAA)
Operating time, approx.
>5h
Weight according to EPTA-Procedure 01:2014
0.27 kg
Dimensions (length x width x height)
65x65x65mm
Cross-line Laser Quigo Plus
1) The working range can be decreased by unfavourable environmental conditions (e. g. direct
sun irradiation).
The measuring tool can be clearly identified with the serial number 8 on the type plate.
